| Model | RD18000KSE-3 |
| Rated Frequency (HZ) | 50 |
| Rated Output Power (KW) | 15 |
| Max Power (KW) | 14.5 |
| Rated Voltage (V) | 220/380 |
| Power Factor | Three 0.8 (lag) |
| Insulation | F |
| Pole No. | 2 |
| Exciting Way / Panel Type | Brush, exciting-self voltage-constant (with AVR) T: General panel / TA: Intelligent panel |
| Output Socket | Single-phase socket, wiring terminal, single-phase socket, Three-phase socket |
| DC12V Output | 12V, 8.3A |
| Dimensions (mm) | 1270*680*795 |
| Net Weight (KG) | 272 |
| Noise (7m) dB | 78 |
| Structure Type | Silent, Fully-Closed |
| Engine Model | R2V95 |
| Engine Type | V-twin, two-cylinder, four-stroke |
| Cylinder NO. – Bore*Stroke (mm) | 95*88 |
| Total Displacement (L) | 1.247 |
| Compressed Ratio | 20:1 |
| Cooling Way | Air-cooled |
| Lubricating Way | Pressure & Splashing |
| Starting Way | Electric |
| Fuel Used | 0# (summer) -10# (winter) -35# (cold winter) light diesel |
| Oil Used | SAE10W30 (CD grade above) |
| Lubricating Oil Capacity (L) | 2.7 |
| Starting Motor Capacity (V-KW) | 12V 1.4KW |
| Dynamo Capacity (V-A) | 12V 8.3A |
| Battery Capacity (V-AH) | 12V 36AH |
